To remove a processor:
1. Disengage the load lever.
2. Lift the retention plate to expose the socket body.
3. Grasp the processor by its edges and lift it out of its socket.
Figure 33 Removing the processor
CAUTION: The pins of the socket are very fragile. Do not bend or damage them.
CAUTION: Place the processor on a static-dissipating work surface or in an anti-static bag.
CAUTION: There must be good contact between the heat sink base and the top of the processor. To
ensure good contact, you must apply thermal interface material.
To apply the thermal grease compound:
1. Use a clean cloth dipped in rubbing alcohol to clean the contact surface on the heat sink and on
the new processor. Wipe the contact surfaces several times to make sure that no particles or dust
contaminants are evident.
2. Apply the thermal grease compound to the CPU contact surface.
CAUTION: HP recommends using Shin-Etsu X-23-7783D thermal grease compound for your ProLiant
server.
3. Apply all the grease to the top of the processor in one of the following patterns to ensure even
distribution.
