General
Output Modes
Sine and pseudo random with burst and band
translation, arbitrary waveform with loop or continuous
output
Frequency Bands
Sine, noise modes
Reconstruction filter bandwidth
DSP data rate (Fs)
Data word size
0 to 25.6 kHz
48.00 kHz to 65.536 kHz
16 bits
Arb modes
Reconstruction filter bandwidth
Data word size
0 to 6.4 kHz
20 bits
Frequency Accuracy ± 0.012% (120 ppm)
Signal Output
Number of Output Channels
1
Maximum Amplitude 10 Vp nominal
Output Impedance < 0.5 Ω (typical)
Maximum Output Current 100 mA (typical)
Maximum Capacitive Load 0.01 µF (typical)
Amplitude Control
(signal amplitude = range × scale factor)
Maximum amplitude
Amplitude ranges
Amplitude scale factor
10 Vp nominal
79 mVp to 10 Vp in 0.375 dB steps
0.0 to 1.0, with 20-bit resolution
Residual Output Noise Voltage
(Freq > 500 Hz) < 500 nV/√Hz
Residual DC Offset
Offset after autozero
Offset after shutdown
Zeroing resolution
± 2 mV
± 20 mV
100 µV
Output Overload Trip > 17 V
Amplitude Ramp-down Time (Programmable) 0 to 30 seconds
Shutdown
Shutdown input
Shutdown time
Shutdown time, ac fail
TTL levels
< 5 s
< 4 ms
Option 1D4 Arbitrary Source
