The Arbitrary Source Option Front Panel

The HP E1432A with the Arbitrary Source Option may have 4, 8, and 16
input channels. The following illustration shows a front panel for 16
channels. The LED’s and connectors are described on the next page.

HP E1432A

Fail

Acs

Source

COLA

Shut

Out

16 CHANNEL
51.2 kSa/s
Digitizer + DSP

Chan
1 - 4

Chan
5 - 8

Chan
9 - 12

Chan

13 - 16

Figure 6-14: HP E1432A with source option - front panel

HP E1432A User's Guide
The Arbitrary Source Option

6-4
