HP VXI E1432A - Manual (Page 169)

2B
If your module has option AYF do the following: Remove the AYF option assembly, see
“To remove the option AYF assembly.” Remove the 5 long and the 3 short standoffs using a
1/4-inch nut driver.
2C
If your module has option 1D4 do the following: Remove the 1D4 option assembly, see
“To remove the option 1D4 assembly.” Remove the 3 long and the 5 short standoffs using a
1/4-inch nut driver.
HP E1432A User's Guide
Replacing Assemblies
10-24
