A-6

A

P

P

E

N

D

I

X

A:

S

P

E

C

I

F

I

C

A

T

I

O

N

S

This section describes:

■

Console Port Pinouts

■

Auxiliary Port Pinouts

■

DB-25 Null Modem Cable

■

Serial Port Pinouts

Console Port

Pinouts

This section lists the cable pinouts for the:

■

DTE console port

■

Mini-DIN to DB-25 modem cable

DTE Console Port

Table A-9 lists pinouts for the console port on the Edge Router module.

Table A-9

Console Port Pinouts (DTE)

Pin

Signal

Input/Output

1

DTR

Output

2

Not Connected

3

TXD

Output

4

GND

5

RXD

Input

6

Not Connected

7

DCD

Input

8

Not Connected
