Quick Installation 2-5
Quick Installation
for Managed Hubs
Follow the general steps outlined in Table 2-2 to install and configure the
Edge Router module in a managed ONline or ONcore hub.
Table 2-2 Quick Installation for Managed Hubs
Step Procedure Refer to:
1 Unpack the module. Unpacking Procedures on page 2-6
2 Verify the jumper plug positions on
the base and expansion engines
Verifying Jumper Plug Positions on
page 2-7
3 Insert the module into an open slot in
the hub.
The appropriate installation
instructions for your hub type in this
chapter
4 Configure the carrier for possible
operation in an unmanaged hub.
Configuring DIP Switches on page 2-8
5 Attach a management terminal to the
Edge Router console port.
Configuring the Edge Router Engine
on page 3-9
6 Configure the carrier using network
management commands.
Configuring the Carrier in a Managed
ONline Hub on page 3-4
or
Configuring the Carrier in a Managed
ONcore Hub on page 3-5
7 Configure the engine parameters
using Cisco Systems setup
command.
Cisco Systems Getting Started Guide
8 Attach WAN cables to the 60-pin
universal WAN connectors on the
front panel.
Cable Pinouts on page A-5
