hp photosmart 7600 series

chapter 1

4

printer parts

front

photo tray

Paper catch

Lift this tray to load

paper

Input bay door

Lift this door to

access the memory

card slots and the

direct-printing port

In tray

Place paper or

envelopes in this

tray for printing

Top cover

Lift the top cover

to change the

print cartridges

Paper length guide

Adjust this guide to

fit close to the end

of the paper in the

In tray

Paper width guide

Adjust this guide to

fit close to the edge

of the paper in the

In tray

LCD screen

Use this screen to determine

the status of your printer

and the current print

settings

Paper catch

extension

Flip this guide open

to catch the

printed paper

Input bay

Use this bay to insert

a memory card or to

connect your HP

direct-printing digital

camera or your

notebook computer

to the direct-printing

port

Out tray

Remove this tray to

load small media

and to clear a

paper jam

Photo tray slider

Move this slider to

engage or disengage

the photo tray

Photo tray

Lift the paper catch to

load 4 x 6 inch (10 x

15 cm) photo paper in

the photo tray

Photo tray paper length

guide

Adjust this guide to fit

close to the end of the

paper in the photo tray

Photo tray paper

width guide

Adjust this guide to

fit close to the edge

of the paper in the

photo tray
