Heat & Glo • RED40, RED40ST • 2155-900 Rev. P • 10/12
69
Service Parts
Beginning Manufacturing Date: May 2009
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Dual Wall Switch Plate 2155-511
Fiberglass Rope 060-455
Flexible Duct Connector 8 FT 2155-360
Glass Latch Support Assembly Qty 4 req 2155-045 Y
Grommet, 3-Hole 2118-420
High Limit Switch Qty 2 req 514-530 Y
High Temp Limit Switch Assembly 046-018A Y
Hood Clips Pkg of 24 047-805-24 Y
Jumper Wire 2 in 1/4 F to 1/4 F 2155-033 Y
Jumper Wire 3/16 F to 1/4 F 2155-035 Y
Jumper Wire 3/16 M to 1/4 F 2155-034 Y
Pilot Bracket 2155-176
Pilot Support Bracket Assembly 2155-009
Restrictor 3” 2155-145
Restrictor 4” 2155-162
Retainer clip Qty 9 req 2155-199
Touch Up Paint TUP-GBK-12
Wall Switch WSK-21-W
Wall Switch Wire 062-550
Wire Harness 20 inch Female 107-559A Y
Conversion Kit NG NGK-RED40 Y
Conversion Kit LP LPK-RED40 Y
Pilot Orifi ce NG 593-528 Y
Pilot Orifi ce LP 593-527 Y
Regulator NG NGK-DXV Y
Regulator LP LPK-DXV Y
Unique service parts by model on following page.
RED40, RED40ST
