Heat & Glo • RED40, RED40ST • 2155-900 Rev. P • 10/12 20
D. Mantel and Wall Projections
WARNING! Risk of Fire! Comply with all minimum clear-
ances to combustibles as specifi ed. Framing or fi nishing
material closer than the minimums listed must be construct-
ed entirely of noncombustible materials (i.e., steel studs,
concrete board, etc).
Combustible Mantels
Figure 5.8 Mantel Leg or Wall Projections
(Acceptable on both sides of opening)
Combustible Mantel Legs Or Wall Projections
Extending Past The Face Of The Fireplace
UNLIMITED
6 IN.
MIN.
2 IN.
MIN.
FIREPLACE
OPENING
4 IN.
MAX.
= ACCEPTABLE
NON-COMBUSTIBLE
MANTEL LEG
ZONE
Note: For non-combustible fi replace fi nish material (marble,
stone, etc) specifi cations refer to Section 13.
Non-Combustible Mantels
Figure 5.6 Minimum Vertical and Maximum Horizontal
Dimensions of Combustibles
Figure 5.7 Minimum Vertical and Maximum Horizontal
Dimensions of Non-Combustibles
MEASUREMENTS FROM
TOP EDGE OF THE OPENING
7
8
9
10
11
12
13
31
TO CEILING
9
10
11
12
8
7
6
25
18
Note: All
measurements
in inches.
MEASUREMENTS FROM TOP EDGE OF THE
FIRESCREEN DOOR ASSEMBLY
8
9
10
16
7
6
5
4
1
2
3
4
5
6
12
31
MAX.
MIN.
TO CEILING
1/2
Note: All
measurements
in inches.
