Heat & Glo • RED40, RED40ST • 2155-900 Rev. P • 10/12
29
Figure 7.10
INSTALLED
HORIZONTALLY
H
1
H
2
V
1
V
2
Top Vent - Vertical Termination
Venting with 3 elbows
Note: Use DVP Series
components only. V
1
+ V
2
Minimum H
1
+ H
2
Maximum
1 ft. 305 mm 2 ft. 610 mm
2 ft. 610 mm 4 ft. 1219 mm
3 ft. 914 mm 9 ft. 2743 mm
4 ft. 1219 mm 12 ft. 3658 mm
5 ft. 1524 mm 15 ft. 4572 mm
V
1
+ V
2
+ H
1
+ H
2
= 63 ft. (19.2 m) Maximum
H
1
+ H
2
= 23 ft. (7.1 m) Maximum
Note: 12 inches minimum vertical is
required prior to attaching any elbow
to the appliance.
NOTE: Maximum total vent run= Total vertical vent run + Total horizontal vent run
MAXIMUM
VERTICAL
DROP
DIRECT VENT WITH 5 in. / 8 in. DIAMETER DVP PIPE
MAX. ELBOWS
(45° & 90°)
MAX. TOTAL VENT
RUN (FT.)
MAX. VERT.
DROP (FT.)
8 80 ft. 12 ft.
Note: The RED40 has been approved for use with
the PVK-80 power vent system.
Figure 7.11 Power Vent
