Heath Zenith Motion Sensor Light Control 9700LeD - Manual (Page 5)

5 598-1360-00
trOuBLeshOOting guiDe
symptOm pOssiBLe Cause sOLutiOn
Lights will not come
on. 1. Light switch is turned off.
2. Lamp is loose or burned out.
3. Fuse is blown or circuit breaker is turned
off.
4. Daylight turn-off is in effect.
5. Incorrect circuit wiring, if this is a new
installation.
6. Sensor is not aimed toward desired cover-
age area.
1. Turn light switch on.
2. Check lamp and replace if burned out.
3. Replace fuse or turn circuit breaker on.
4. Recheck after dark.
5. Verify wiring is correct.
6. Re-aim sensor to cover desired area.
Lights come on in
daylight. 1. Light control may be installed in a relatively
dark location.
2. Light control is in TEST.
1. The fixture is operating normally under these
conditions.
2. Set control switch to 1, 5, or 10 minutes.
Lights come on for no
apparent reason. 1. Light control may be sensing small animals
or automobile traffic.
2. Range is set too high.
1. Reduce Range. Re-aim sensor.
2. Reduce Range.
Lights stay on
continuously. 1. The sensor may be picking up a heat source
like an air vent, dryer vent, or brightly
painted, heat-reflective surface.
2. Sensor is in Manual Override mode.
1. Reduce Range. Re-aim sensor.
2. Set control switch to 1, 5, or 10 minutes.
Follow manual override instructions to reset.
Lights flash on and
off. 1. Heat or light from the lamps may be turning
the light control on and off.
2. Heat being reflected from other objects
may be affecting the sensor.
3. Sensor is in the Test mode.
4. Light may be leaking through the flood
lamp reflectors
1. Reposition the lamps away from the sensor.
2. Reduce Range. Re-aim sensor.
3. While in TEST mode, light only stays on for 5
seconds.
4. Make sure the metal lamp protectors are in-
stalled.
