Hearth & Home Technologies • DV3732SBI, DV3732SBIL • 2215-900 Rev. G • 2/13 58
MODEL DESCRIPTION PART #
ELEVATED APPLIANCE
DIMENSION
See Note 1
MARBLE LEG CUT
LENGTH
See Note 2
DV3732SBI
DV3732SBIL
KENWOOD CABINET KDC44SBP 0 29-3/8 in.
KENWOOD CABINET W/ BASE KDC44SBP W/ HTKDC44SBP 9-1/4 in. 29-3/8 in.
KENWOOD CORNER CABINET KDA44SBP 0 29-3/8 in.
KENWOOD CORNER CABINET W/ BASE KDA44SBP W/ HTKDA44SBP 9-1/4 in. 29-3/8 in.
KENWOOD MANTEL AFKDMPA 0 (See Note 3) 27-3/8 in.
KENWOOD MANTEL W/ BASE AFKDMPA W/ HTKDMPA 9 1/4 in. 29-3/8 in.
LUNA SURROUND LUNA-32-GY 1-1/16 in. N/A
E. Elevated Hearth Systems
Use the table below to identify the hearth system that will be used. The table will also help identify effects on the various
dimensions. Some hearth systems will elevate the appliance off the fl oor at a given dimension. For example, if appliance
will be used with a Kenwood Cabinet with Base, the appliance will be elevated 9-1/4 in. The 9-1/4 in. elevation will also
have to be added to the following: Wall penetration referenced in Figure 8.2 (Wall penetration) and Rough Opening Height
(header height) referenced in Figure 5.2. Note: Finished fl oor thickness should also be considered when determining in-
stallation dimensions.
Note 1. Add dimensions to Wall Penetration (Figure 8.2) and Rough Opening Height (Figure 5.2).
Note 2. Verify Marble Cut Lengths on site prior to cutting.
Note 3. Dimensions assume use of a 3/4 in. Hearth Pad.
