33 Hearth & Home Technologies • DV3732SBI, DV3732SBIL • 2215-900 Rev. G • 2/13
V
1
MIN. H
1
MAX. H
2
MAX. H
1
+ H
2
MAX.
Back to back elbows 1-1/2 ft. 457 mm 1 ft. 305 mm 2-1/2 ft. 762 mm
1 ft. 305 mm 3-1/2 ft. 1.1 m 3 ft. 914 mm 6-1/2 ft. 2.0 m
2 ft. 610 mm 5-1/2 ft. 1.7 m 5 ft. 1.5 m 10-1/2 ft. 3.2 m
3 ft. 914 mm 7-1/2 ft. 2.3 m 7 ft. 2.1 m 14-1/2 ft. 4.4 m
H
1
MAX. = 7-1/2 ft. (2.3 m)
H
1
+ H
2
MAX. = 14-1/2 ft. (4.4 m)
V
1
+ V
2
+ H
1
+ H
2
MAX. = 40 ft. (12.2 m)
Figure 7.18
Three elbows
Note: Use DVP Series
components only.
V
2
V
1
H
2
H
1
4. Rear Vent - Vertical Termination - (continued)
