29 Hearth & Home Technologies • DV3732SBI, DV3732SBIL • 2215-900 Rev. G • 2/13
2. Top Vent - Vertical Termination - (continued)
Four 90º Elbows
Figure 7.11
V
1
MIN. H
1
MAX. V
2
MIN. H
2
MAX. V
3
MIN.
1-1/2 ft. 457 mm 4 ft. 1.2 m 4 ft. 1.2 m 4 ft. 1.2 m 3-1/2 ft. 1.0 m
V
1
+ V
2
+ V
3 +
H
1
+ H
2
Maximum= 40 ft. (12.2 m) Note: Use SLP Series
components only.
V
1
H
1
V
2
V
3
H
2
Note: There MUST be a 25% reduction
in total H when using fl ex vent except
when using the simple up and out
installation (see Figure 7.3).
