365262 4/07 6-5
52" Deck Pulley Assembly
NOTES:
1. Torque to 118 ft. lbs.
2. See “Deck Belt Routing and Tensioning” on page 7-3 for belt tensioning.
3. Used on mowers with serial number prior to 02017202 (FIG. 6-1).
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 784249 784249 1 B-SECTION BELT
2 016972 016972 2 NT .625-11 HX G5 ZNYC
3 046821 046821 3 FW .656 X 2.00 X .078 ZNYC
4 797449 797449 3 FW .650X1.00X.180 ZNYCG5
5 784504 784504 3 5.00" OD, 5/8" ID IDLER PULLEY
6 797910 797910 6 CS .312-18X1.50FLT SH ZY
7 600171 600171 1 UHMW DECK IDLER CLAMP
8 600189 600189 1 IDLER SLIDE UHMW RS
9 794446 794446 1 CS .625-11 X 1.50 HX G5 ZNYC
10 600296 600296 1 SPACER DECK IDLER
11 350884 350884 1 DECK IDLER
12 786335 786335 1 UHMW (.03 THICK)
13 781302 781302 1 IDLER SPRING
14 259812 059931 1 SPRING CHAIN
15 361147 361147 1 R.S. PULLEY COVER
16 361154 361154 1 L.S. PULLEY COVER
17 064006 064006 4 CS .312-18 X .625 HX G5 ZNYC
18 768523 768523 10 FW .343 X.687 X .051/.080HD ZNYC
19 781872 781872 6 CS .625-11 X 1.25 HX G5 ZNYC
20 782474 782474 8 CW .631 2.250 X .187 PNT
21 786889 786889 3 DECK DRIVE 5.25 PULLEY
22 783506 783506 3 BLADE SPINDLE ASSEMBLY
23 783753 783753 3 18" X 2.50 X 0.204 .631 DIA BLADE
24 005116 005116 12 CS .375-16 X 1.375 HX G5 ZNYC
25 767954 767954 24 FW .406 X .812 X .060 SAE HD ZN
26 783738 783738 2 CS .625-11X3.00 FULL HX G5 ZN
27 054502 054502 12 NT .375-16 HX GRD 5 ZNYC
28 058776 058776 6 NT .312-18 HX NL ZNYC
29 079186 079186 6 CS .312-18 X 1.25 HX G5 ZNYC
30 712927 712927 6 FW .344 X 1.00 X.12 HRD ZNYC
31 358317 358317 1 DECK IDLER
32 364315 364315 1 SPRING CHAIN
33 028118 028118 3 FW .62 X 1.00 X.134 ZNYC
34 102970 102970 1 MINI Z IDLER DECK
35 787069 787069 2 UHMW RISER DECK IDLER
36 785832 785832 2 UHMW CLAMP DECK IDLER
783878 N/A 2 UHMW IDLER CLAMP
37 017129 017129 6 FW .440 X 1.000 X .083 ZNYC
38 784199 784199 6 CS .312-18 X1.25 FLT SH ZNYC
40 720193 720193 1 FW .656 X 1.125 X .06 ZNYC
10
10
10
10
10
9
7
4
4
4
4
4
7
5
8
3
6
6
10
