365262 4/07 4-3
Honda 18 & 20 HP Engine Installation
NOTES:
1. Part of Item 11 (784868 FasTrak wire harness).
2. Two wires.
3. Connected to Item 11 (784868 FasTrak wire harness).
4. Torque to 45-48 ft-lb.
5. Engine oil capacity; 2.3 US qts. (with filter), see engine manual.
6. Engine speed; High speed - 3450 ±50 RPM.
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 784629 784629 1 HONDA 20HP ENGINE
784611 784611 1 HONDA 18HP ENGINE
2 784843 784843 1 18/20 HONDA MUFFLER
3 720177 720177 2 CS M 8-1.25 X 20 10.9 HX FL ZNYC
4 785378 785378 1 EXHAUST PIPE CLAMP
5 784959 784959 1 FASTRAK MUFFLER MANIFOLD
6 785543 N/A 2 HONDA (20) MUFFLER GASKET
7 017004 N/A 4 LW .312 MED SPRING ZNYC
8 782664 N/A 4 NT M8-1.25 HX STAINLESS STEEL
9 050161 050161 1 CS .312-18 X 1.75 HX G5 ZNYC
10 000398 000398 1 CLAMP
11 784868 784868 1 FASTRAK WIRE HARNESS
12 024927 024927 2 NT .250-20 HX GR 5 ZNYC
13 017038 017038 2 LW .250 MED SPRING ZNYC
14 785477 N/A 1 HONDA 20 AMP RECTIFIER
15 056077 056077 2 CS .250-20 X 1.00 HX G5 ZNYC
16 768515 768515 2 FW .250 X .560 X .04 SAE ZNYC
17 712372 712372 1 KEY 1/4 SQ X 0.66 LONG
18 786616 786616 1 PUMPDRIVE PULLEY
19 784835 784835 1 FASTRAK CLUTCH
20 763417 763417 1 FW .454 X 1.50 X .250
21 785048 785048 1 CS .437-20 X 3.00 HX G5 ZNYC
22 785063 N/A 1 POSITIVE BATTERY CABLE
23 785071 N/A 1 NEGATIVE BATTERY CABLE
24 034272 034272 5 NT .312-18 HX G5 ZNYC
25 768523 768523 3 FW .343 X .687 X .051/.080 HD ZNYC
26 712927 712927 4 FW .344 X 1.00 X .12 HRD ZNYC
27 029876 029876 4 LW .312 INT-EXT TOOTH ZNYC
28 052837 052837 4 CS .312-18 X 1.500 HX G5 ZNYC
29 000331 000331 1 SMALL/SHORT WIRE TIE
30 791251 N/A 1 CLUTCH WIRE HARNESS PIGTAIL
31 784918 784918 1 RUBBER BUMPER
