365262 4/07 3-5
Deck Lift Assembly
NOTES:
1. Apply grease to zerks (see owners manual).
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 348318 348318 1 STOP HANDLE
2 348284 348284 1 HEIGHT ADJUSTOR STOP
3 781294 781294 7 CLIP E, 1.00 X .625 X .050
4 784686 784686 6 FW .812 X 1.469 X .134 THK ZNYC
5 782995 018846 2 DECK LIFT SPRING
6 055749 055749 3 CS .437-14 X 1.750 HX G5 ZNYC
7 360131 360131 4 DECK LIFT CHAIN
8 704643 704643 8 NT .437-14 HX FLG ZN
9 781831 781831 1 CS.437-14 X 1.750 FULTH G5 ZNYC
10 781229 781229 1 CE .750 X 2.25 X 1.75 HEADLESS
11 784488 784488 1 DECK LIFT INDICATOR
12 756270 756270 1 CS .312-18 X 1.50 FLTHR GR5 ZNYC
13 034272 034272 1 NT .312-18 HX G5 ZNYC
14 348458 348458 1 DECK LEVELER YOKE
15 767962 767962 2 FW .531 X 1.063 X .090 SAE HD ZN
16 015495 015495 4 GREASE FITTING STRAIGHT
