365262 4/07 6-3
52" Deck Assembly
NOTES:
1. Factory assembled in top hole for shipping purposes.
2. Includes items 12 through 15.
3. When ordering replacement decks, also order 6 each of Items 6 and 7, 1
each of Item 8, 9, and 12, from Deck Pulley Assembly. Replacement
decks include decals, see “52" Deck Decals” on page 8-4.
4. Includes one each of:
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 357111 357111 1 FASTRAK DISCHARGE CHUTE
2 063297 063297 2 SB .375 X .500 SH .312-18 TD ZN
3 058776 058776 2 NT .312-18 HX NL ZNYC
4 767954 767954 8 FW .406 X .812 X .060 SAE HD ZN
5 054502 054502 2 NT .375-16 HX GRD 5 ZNYC
6 357103 357103 1 DISCHARGE CHUTE MOUNT BRACKET
7 034280 034280 2 CS .312-18 X .750 HX G5 ZNYC
8 768523 768523 4 FW .343 X .687 X .051/.080HD ZNYC
9 787994 787994 2 DECK PIN & ROD ASSEMBLY
10 034272 034272 2 NT .312-18 HX G5 ZNYC
11 781880 781880 1 .500X 1.00X .312 X.188 BUMPER
12 781708 N/A 4 CS .500-13 X 4.250 HX G5 ZNYC
13 767962 N/A 12 FW .531 X 1.063 X.090 SAE HD ZN
14 031997 N/A 4 ANTI-SCALP WHEEL
15 053199 N/A 4 NT .50-13 HX JAM ZNYC
16 781567 781567 4 NT .50-13 HX LK NY
17 545970 356212 1 52" FASTRAK DECK
788166 788166 4 ANTI SCALP WHEEL ASSEMBLY
18 055822 055822 2 CS .375-16 X .750 HX G5 ZNYC
19 N/A 808485 4 5/16-18 THREAD RIVET NUT
784736 DECK PULL ROD ASSY
362988 DECK PIN
4
3
2 1
