365262 4/07 4-13
Fuel System Installation
NOTES:
1. Torque to 20 ft.-lbs.
2. Supplied with new fuel tank.
3. Length for mowers with Honda engines only.
4. Length for mowers with Briggs & Stratton engines only.
5. Length for mowers with Kohler engines only.
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 784181 784181 2 FUEL TANK CAP
2 796318 796318 1 R.S. FUEL TANK
3 796326 796326 1 L.S. FUEL TANK
4 055822 055822 12 CS .375-16 X .750 HX G5 ZNYC
5 712919 712919 12 FW .406 X 1.00 X .12 HRD ZNYC
6 000331 000331 5 SMALL/SHORT WIRE TIE
7 015818 015818 1 FUEL LINE, 33”
8 015818 015818 1 FUEL LINE, 35"
015818 015818 1 FUEL LINE, 21"
015818 015818 1 FUEL LINE, 12"
9 015818 015818 1 FUEL LINE, 14"
10 791277 N/A 2 FUEL TANK 90° FITTING
11 000323 000323 6 CLIP
12 745059 745059 1 FUEL VALVE 3-WAY
3
4
5
2
