365262 4/07 3-9
Hydro Transmission Installation
NOTES:
1. Service parts for Left/Right Pump/Motor Combo:
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 784231 784231 1 A-SECTION PUMP BELT
2 025007 025007 2 CS .625-11 X 1.750 HX G5 ZNYC
3 028118 028118 2 FW .62 X 1.00 X .134 ZNYC
4 784827 784827 2 4.00"OD, 5/8"ID IDLER PULLEY
5 061101 061101 1 NT .750-10 HX NL ZN
6 025296 025296 1 FW .760 X 1.625 X .08 ZNYC
7 781153 781153 2 UHMW BUSHING
8 363788 363788 1 PUMP IDLER
9 781302 781302 1 IDLER SPRING
10 050161 050161 1 CS .312-18 X 1.750 HX G5 ZNYC
11 034272 034272 14 NT .312-18 HX G5 ZNYC
12 043067 043067 6 CS .312-18 X 3.00 HX G5 ZNYC
13 768523 768523 14 FW .343 X .687 X .051/.080 HD ZNYC
14 712927 712927 10 FW .344 X 1.00 X .12 HRD ZNYC
15 785113 785113 6 CS .312-18 X 4.250 HX G5 ZNYC
16 361212 361212 1 LOWER MOUNT SUPPORT
17 788067 788067 1 LEFT PUMP/MOTOR COMBO
18 788059 788059 1 RIGHT PUMP/MOTOR COMBO
19 786301 786301 1 IZT BREATHER SLEAVE
784306 RIGHT HAND PARKING PAWL
784314 LEFT HAND PARKING PAWL
785725 FAN
785717 PULLEY
785733 SEAL KIT
