365262 4/07 3-7
Steering and Brake Assembly
NOTES:
1. Includes two (2) of 768259 (Ingus Bushing, #MFI-0810-05).
2. Includes 078386 FW and 784819 Retaining Ring.
3. Includes Item 1 (781260 Steering Bar Grip).
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 781260 N/A 2 STEERING BAR GRIP
2 360487 360487 2 STEERING BAR
3 086660 086660 6 NT .375-16 HX LK NY
4 767954 767954 14 FW .406 X .812 X .060 SAE HD ZN
5 705178 705178 6 CS .375-16 X 1.750 HX G5 ZNYC
6 363812 363812 2 STEER ARM SUPPORT
7 360677 360677 2 STEERCRANK LEVER
8 768523 768523 31 FW .343 X .687 X .051/.080 HD ZNYC
9 768259 N/A 4 INGUS BUSHING, #MFI-0810-05
10 362251 362251 2 CRANK PIVOT
11 036236 036236 9 CS .312-18 X 1.000 HX G5 ZNYC
12 034272 034272 12 NT .312-18 HX G5 ZNYC
13 784405 784405 2 FIXED ASSEMBLY PUMP ROD
14 784355 784355 1 LH PUMP ROD ADJUSTER ASSEMBLY
15 784371 784371 1 RH PUMP ROD ADJUSTER ASSEMBLY
16 781211 781211 2 PUSH BUTTON SWITCH
17 063198 063198 4 CS 10-24 X .75 HXFLK ZNYC
18 059832 059832 6 NT #10-24 HX NL ZN
19 770867 770867 8 PLASTIC BUSHING, .750 X 1.00 X .50
20 784439 784439 4 LOCK COLLAR .750"
21 359737 359737 2 BRAKE TUBE
22 359745 359745 2 BRAKE LINK
23 784421 784421 2 BRAKE TENSION SPRING
24 023655 023655 6 NT .312-24 HX NL ZNYC
25 017251 017251 2 CP .156D X 1.000 LG HML ZN
26 785162 785162 2 SB .250 X 1.00 SH #10-24 ZNYC
27 787879 787879 1 LH ROLLER ARM
28 787887 787887 1 RH ROLLER ARM
29 363176 363176 1 LEFT STEER ARM SUPPORT
30 361550 361550 1 RIGHT STEER ARM SUPPORT
31 783696 783696 2 CENTERING DAMPENER
32 781922 781922 4 DAMPER BALL STUD
33 361295 361295 1 PIVOT TUBE
3
1
2
2
