365262 4/07 4-15
Instrument Panel Assembly/Installation
NOTES:
1. Part of 784868, 786186, 792754 or 786178 (Tractor Wire Harness).
2. Used on CE models only.
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 785196 785196 1 CHOKE CABLE (HONDA 18 & 20 AND KOHLER ENGINES)
785030 785030 1 CHOKE CABLE (HONDA 16) ENGINE
786657 786657 1 CHOKE CABLE (17.5 BRIGGS, STRATTON ENGINE)
2 776476 776476 1 PTO SWITCH
3 712257 712257 1 RED INDICATOR LIGHT
4 785808 785808 1 KEY ASSEMBLY
5 045898 045898 1 KEY SWITCH
6 714998 714998 2 MS #10-24 X .625 HX ZN
7 704932 704932 4 FW .219 X .500 X .048 ZNYC
8 059832 059832 4 NT #10-24 HX NL ZN
9 365411 365411 1 INSTRUMENT PANEL
10 026237 N/A 2 RELAY
11 768879 768879 1 ENGINE CONTROLS CABLE (HONDA 18 & 20, KOHLER AND , & 17.5 BRIGGS)
787788 787788 1 THROTTLE CABLE ASSEMBLY (HONDA 16 ONLY)
12 055947 055947 3 CS .250-20X .500 HX G5 ZNYC
13 768515 768515 3 FW .281 X .625 X .051/.080 HD ZNYC
14 102707 102707 1 CE THROTTLE STOP
