Kohler 18 & 20 hp engine installation – Hustler Turf Lawn Mower User Manual
Page 31
365262 4/07
4-9
Kohler 18 & 20 HP Engine Installation
NOTES:
1. Included with engine.
2. Part of item 3 (792754 FasTrak Kohler wire harness).
3. Torque to 45-48 ft-lb.
4. Engine oil capacity: 1.6 US qts.
5. Engine speed: 3600 ±50 RPM.
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY.
DESCRIPTION
1
792713
792713
1
KOHLER 18 HP SV540S ENGINE
792721
792721
1
KOHLER 20 HP SV600S ENGINE
2
739144
739144
1
CS M 6-1.0 X 12 10.9 HXFL ZN
3
792754
792754
1
FST 44/52 KOHLER WIRE HARNESS
4
055939
055939
2
CS .250-20 X .750 HX G5 ZNYC
5
768515
768515
6
FW .281 X .625 X .051/.080 HD ZNYC
6
044255
044255
1
NT #10-32 HX ZN
7
030817
030817
1
STARTER SOLENOID
8
792762
792762
1
RED 9" BATTERY CABLE
9
024927
024927
4
NT .250-20 HX GR.5 ZNYC
10
793885
793885
4
LW .375 INT-EXT TOOTH
11
036244
792788
4
CS .375-16X1.000 HX G5 ZNYC
12
712372
712372
1
KEY 1/4 SQ X 0.66 LONG
13
786616
786616
1
PUMPDRIVE PULLEY
14
000331
000331
1
SMALL/SHORT WIRE TIE
15
791251
N/A
1
CLUTCH PIGTAIL, WIRE HARNESS
16
784835
784835
1
FASTRAK CLUTCH
17
763417
763417
1
FW .454 X 1.50 X .250
18
785048
785048
1
CS .437-20 X 3.00 HX G5 ZNYC
19
796516
796516
1
VALVE,OIL DRAIN 3/8-18
20
104786
104786
1
OIL DRAIN HOSE
21
768523
768523
9
FW .343 X .687 X .051/.080 HD ZNYC
22
043570
043570
1
SINGLE HOSE CLIP
23
017004
017004
2
LW .312 MED SPRING ZNYC
24
782664
782664
2
NT M8-1.25 HX STAINLESS
25
034272
034272
3
NT .312-18 HX G5 ZNYC
26
792739
792739
1
18/20HP KOHLER COURAGE MANIFOLD
27
792747
792747
1
18/20HP KOHLER COURAGE MUFFLER
28
016253
016253
2
CB .312-18 X .750 FUL ZN
29
794180
794180
1
1.125" EXHAUST CLAMP
30
034280
034280
5
CS .312-18 X .750 HX G5 ZNYC
31
756270
756270
1
CS .312-18 X 1.50 FLTHR GR5 ZNYC
32
337444
337444
1
FST - KOHLER ENGINE GUARD
33
781708
N/A
2
CS .500-13 X 4.25 HX G5 ZNYC
34
767962
N/A
4
FW .531 X 1.063 X .090 SAE HD ZN
35
031997
N/A
2
ANTI-SCALP WHEEL
36
053199
N/A
2
NT .500-13 HX JAM ZNYC
37
344267
344267
4
FW .510 X 2.15 X .187 SPL ZNYC
38
781567
781567
2
NT .50-13 HX LK NY ZNYC
788166
788166
2
ANTI SCALP WHEEL ASSY
7
6
