Hustler Turf Lawn Mower - Manual (Page 27)

365262 4/07 4-5
Honda 16 HP Engine Installation
NOTES:
1. Part of item 11 (786178 FasTrak 16 Honda Wire Harness).
2. Torque to 45-48 ft-lb.
3. Engine oil capacity; 1.37 US qts. (with filter), 1.22 US qts. (w/o filter), see
engine manual.
4. Engine speed; High speed - 3450 ±50 RPM.
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 785394 785394 1 HONDA 16 HP ENGINE
2 785410 785410 1 16 HONDA MUFFLER
3 034280 034280 2 CS .312-18 X .750 HX G5 ZNYC
4 768523 768523 5 FW .343 X .687 X .051/.080 HD ZNYC
5 785378 785378 1 EXHAUST PIPE CLAMP
6 785543 N/A 2 HONDA MUFFLER GASKET
7 005231 005231 4 NT M6-1.0 X10 HX FLG ZN
8 785402 785402 1 FASTRAK 16 HP MUFFLER MANIFOLD
9 034272 034272 7 NT .312-18 HX G5 ZNYC
10 712927 712927 4 FW .344 X 1.00 X .12 HRD ZNYC
11 786178 786178 1 FASTRAK 16 HONDA WIRE HARNESS
12 739144 792796
13 786640 N/A 1 NEGATIVE BATTERY CABLE
14 725267 725267 2 FW .318 X .472 X .047 ZN
15 786632 N/A 1 POSITIVE BATTERY CABLE
16 782664 782664 1 NT M8-1.25 HX STAINLESS STEEL
17 768515 768515 2 FW .250 X .560 X .04 SAE ZNYC
18 017038 017038 2 LW .250 MED SPRING ZNYC
19 056077 056077 2 CS .250-20 X 1.00 HX G5 ZNYC
20 024927 024927 2 NT .250-20 HX GR.5 ZNYC
21 787267 N/A 1 HONDA 16 AMP RECTIFIER
22 029876 029876 4 LW .312 INT-EXT TOOTH ZNYC
23 050161 050161 4 CS .312-18X1.750 HX G5 ZNYC
24 712372 712372 1 KEY 1/4 SQ X 0.66 LONG
25 000331 000331 1 SMALL/SHORT WIRE TIE
26 786616 786616 1 PUMPDRIVE PULLEY
27 791251 N/A 1 CLUTCH WIRE HARNESS PIGTAIL
28 784835 784835 1 FASTRAK CLUTCH
29 784918 784918 1 RUBBER BUMPER
30 763417 763417 1 FW .454 X 1.50 X .250
31 785048 785048 1 CS .437-20 X 3.00 HX G5 ZNYC
32 378273 378273 1 16HP EXHAUST HEAT SHIELD
33 043570 043570 1 SINGLE HOSE CLIP
