365262 4/07 3-3
Battery Installation
NOTES:
1. Used on mowers with Honda 18 & 20 HP engines.
2. Used on mowers with Briggs & Stratton engines, and Honda 16 HP
engines.
3. Used on mowers with Honda 16 HP Engines.
4. Used on mowers with Kohler engines
5. Used on mowers with Briggs & Stratton engines.
6. Battery is not installed on CE units nor in non CE units for sales outside
the U.S.
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 058776 058776 2 NT .312-18 HX NL ZNYC
2 768523 768523 7 FW .343 X .687 X .051/.080 HD ZNYC
3 348417 348417 1 BATTERY CLAMP STRAP
4 055939 055939 2 CS .250-20 X .750 HX G5 ZNYC
5 029868 029868 4 LW .250 INT-EXT TOOTH ZNYC
6 024927 024927 2 NT .250-20 HX GR.5 ZNYC
7 785063 785063 1 POSITIVE BATTERY CABLE
7 786632 786632 1 POSITIVE BATTERY CABLE
793216 793216 1 POSITIVE BATTERY CABLE
8 785071 785071 1 NEGATIVE BATTERY CABLE
8 786640 786640 1 NEGATIVE BATTERY CABLE
795146 795146 1 NEGATIVE BATTERY CABLE
9 740696 740696 1 BATTERY (VU1LH-8)
10 771428 771428 1 BATTERY CABLE BOOT-RED
11 034280 034280 5 CS .312-18 X .750 HX G5 ZNYC
12 034272 034272 2 NT .312-18 HX G5 ZNYC
13 364174 364174 1 BATTERY SUPPORT
14 779850 779850 2 CB .312-18 X 3.00 FUL ZN
1
2
4
5 1
3
4
