6–26 437804-001 Service Reference Guide, dc5700
Removal and Replacement Procedures— Microtower (MT) Chassis
6.11 Front Shroud
1. Prepare the computer for disassembly ( Section 6.1 ).
2. Remove the access panel and rotate the computer so the system board is parallel to the table
to make it easier to work on ( Section 6.3 ).
3. Remove the hard drive cables from the plastic shroud at the front of the chassis and from the
hard drives.
4. Lift the shroud straight up 1 about 5-mm (3/16-in) before pulling it into the chassis 2 to
remove it.
To install the shroud, reverse the removal process.
