ModBus Data Listing
Appendix B
B–36
The following table lists the holding registers for the “C” Group Intelligent Input
Functions.
I
“C” Group Intelligent Terminal Functions
Func.
Code
Name
R/W
Description
Network Data
Reg.
Range
Res.
C001
Terminal [1] function
R/W
00A7h
0, 1, 2, 3,
4, 5, 6, 7,
8, 9, 11,
12, 13,
15, 16,
18, 19,
20, 21,
22, 23,
24, 27,
28, 29,
31, 50,
51, 255
—
C002
Terminal [2] function
R/W
00A8h
C003
Terminal [3] function
R/W
00A9h
C004
Terminal [4] function
R/W
00AAh
C005
Terminal [5] function
R/W
00ABh
C006
Terminal [6] function
R/W
00ACh
C011
Terminal [1] active state R/W Select logic convention, two
option codes:
00... normally open [NO]
01... normally closed [NC]
00ADh
0, 1
—
C012
Terminal [2] active state R/W
00AEh
0, 1
—
C013
Terminal [3] active state R/W
00AFh
0, 1
—
C014
Terminal [4] active state R/W
00B0h
0, 1
—
C015
Terminal [5] active state R/W
00B1h
0, 1
—
C016
Terminal [6] active state R/W
00B2h
0, 1
—
C021
Terminal [11] function
R/W
00B3h
0, 1, 2, 3,
4, 5, 6, 7,
8, 9
—
C022
Terminal [12] function
R/W
00B4h
C026
Alarm relay terminal
function
R/W
00B5h
C028
[AM] signal selection
R/W Two available functions:
00... Actual motor speed
01... Motor current
00B7h
0, 1
—
C031
Terminal [11] active
state
R/W Select logic convention, two
option codes:
00... normally open (NO)
01... normally closed (NC)
00B8h
0, 1
—
C032
Terminal [12] active
state
R/W Select logic convention, two
option codes:
00... normally open (NO)
01... normally closed (NC)
00B9h
0, 1
—
C036
Alarm relay active state
R/W Select logic convention, two
option codes:
00... normally open (NO)
01... normally closed (NC)
00BAh
0, 1
—
