Annex B
Parameter Value for
Y, R, G, B
Value for
Pb, Pr Condition Notes
± 1 dB
20 MHz to 30 MHz
+1 dB/-2.5 dB MHz ± 1 dB
Group delay DC to 30 MHz <
50nS DC to 30 MHz <
50nS
Noise DC to 30 MHz < -
50 dB DC to 30 MHz < -
50 dB 100% ramp
Out-of-band
noise 30 MHz to 100 MHz
< -50 dB 15 MHz to
100 MHz
< -50 dB Sweep
Linearity < 5% < 5% 5 step
Inter-channel
delay < 10 nS < 10 nS 100% colour
bar
Interchannel
crosstalk < -40 dB < -40 dB Multiburst
Blanking rise
and fall time 100 nS ± 50 nS 100 nS ± 50 nS Flat field 20% to
80%
Active line
width
inequality <50 nS <50 nS Flat field
Sync edge to
start of active
picture 2.586uS +80nS/-
0nS 2.586uS +80nS/-
0nS 50% to
50%
Sync
amplitude
Pos and Neg 300mV ± 5% 300mV ± 5%
Tri-level Sync
rise and fall
time 54 nS ± 20 nS 54 nS ± 20 nS 20% to
80%
Output
impedance 75 Ω nominal 75 Ω nominal
Return loss DC to 20 MHz >
20 dB DC to 20 MHz >
20 dB
Table B.6 Sync Output Specification
Parameter Value Condition Notes
H and V Sync.
High Voltage >2.5V 2.2k Ω
H and V Sync.
Low Voltage <0.5V 2.2k Ω
EN/LZT 790 0005 R1A B-6
