Efficient Networks ® Router family
Command Line Interface Guide
Chapter 21: Switch Commands
Efficient Networks
®
Page 21-5
Response
When the command is entered with parameters, a command prompt is returned.
Response when the command is entered with no parameters and port mirroring is
currently disabled:
Typical response when entered with no parameters and port mirroring is currently
enabled:
switch status
Displays the current port states for the Ethernet switch.
Mgmt Class
Network (R)
Input Format
switch status
Parameters
None
-> switch mirror capture 3
->
-> switch mirror
Port mirroring is disabled
-> switch mirror
Port mirroring is enabled:
Port 1: Mirrored Port
Port 2: Capture Port
Port 3: Not Mirrored
Port 4: Not Mirrored
Port 5: Not Mirrored
Port 6: Not Mirrored
Port 7: Not Mirrored
Port 8: Not Mirrored
Port 9: Not Mirrored
