Efficient Networks ® Router family
Command Line Interface Guide
Chapter 5: Ethernet Interface Commands
Efficient Networks
®
Page 5-29
Parameters
Response
Command prompt.
eth ip ripmulticast
Changes the multicast address for RIP-1 compatible and RIP-2 packets. The default
address is 224.0.0.9. For more information, see “
RIP Controls” on page 6-4 of the
Technical Reference Guide.
Mgmt Class
Network (R/W)
Input Format
eth ip ripmulticast
Must be one of the following:.
rxrip Receive and process IP RIP-1 compatible and RIP-2 broadcast
packets from the Ethernet LAN. Also receive and process RIP-
2 packets that are multicast as defined by the eth ip ripmulticast
command. Set this option if the local router is to discover route
information from the Ethernet LAN. The default is on.
rxrip1 Receive and process RIP-1 packets only.
rxrip2 Receive and process RIP-2 packets only.
rxdef Receive the default route address from the Ethernet LAN. The
default is on. This option is useful if you do not want to configure
your router with a default route.
txrip Transmit RIP-1 compatible broadcast packets and RIP-2 multi-
cast packets over the Ethernet LAN. The default is on.
txrip1 Transmit broadcast RIP-1 packets only.
txrip2 Transmit broadcast RIP-2 packets only.
txdef Advertise this router as the default router over the Ethernet
LAN (provided it has a default route). The default is on. Set this
to off if another router on the local LAN is the default router.
advfr
multicast Enables this Ethernet interface to forward IP multicast traffic.
a,b
a This parameter may be omitted if the router has only one Ethernet interface.
If the router has two physical Ethernet interfaces (an Ethernet hub router), the port number (0 or 1) must
be specified.
b
To specify a logical interface other than logical interface 0, specify both the port number and the logical
interface number (:, for example, 0:1).
Ethernet interface.
