Read/write function block data
For more information visit: www.EatonElectrical.com MN05013001E 81
Timing relays: T1 – T16
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 44
1 Command:
Read 89 –
Write 8D –
Response:
Read successful – C2
Write successful – C1
Command rejected – C0 1
2 Type 8E 8E
3 Instance 2 00 – 0F 00 – 0F
4 Index J Table 33
5 – 8 Data 1 – 4 depending on index J Table 34
1) Possible causes J page 91
2) EZ provides 16 timing relays T1 to T16 for use as required. These can
be addressed using the instance (0 – F).
