EZ800/EZD Control Commands
MN05013001E
130
Boolean sequence function blocks BV01 .. BV32
Telegram structure
Byte
Meaning
Value (hex), sent by
Master
Slave
0
Toggle byte
J
page 94
1
Command:
Read
92
–
Write
B2
–
Response:
Read successful
–
C2
Write successful
–
C1
Command
rejected
–
C0
2
Type
13
13
3
Instance
01 – 20
01 – 20
4
Index
J
Table 64
J
Table 64
5 – 8
Data 1 – 4
Read operation
00
depending on
index,
J
Table 65, 66
Write operation
depending on
index,
J
Table 65, 66
00
