EZ800/EZD Control Commands
MN05013001E 98
Example
The real-time clock of the EZ800 is to be set to Friday
23.05.2003, 14:36.
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte 81 80
1 Command: Write B3 –
Response: Write
successful
– C1
2 Len 05 05
3 Index 00 00
4 Data 1 0E 00
5 Data 2 24 00
6 Data 3 17 00
7 Data 4 05 00
8 Data 5 03 00
J
All values must be transferred as hexadecimal values.
