Read/write image data
For more information visit: www.EatonElectrical.com
MN05013001E
59
Example:
Marker M13 is set.
Byte
Meaning
Value (hex), sent by
Master
Slave
0
Toggle byte
J
page 44
1
Command: Write
8C
–
Response:
Write successful
–
C1
Command
rejected
–
C0
1
2
Len
01
01
3
Type
M marker
86
86
4
Index
0C
0C
5 Data
1
01
00
6 – 8
Data 2 – 4
00
00
1) Possible causes J page 91
