Read/write function block data
For more information visit: www.EatonElectrical.com
MN05013001E
153
Table 87: Index 0 – Bit IO
Table 88: Index 1 – Mode/Parameters
(designation of PUT FB
with data to be received)
Bit 7 6 5 4 3
2
1
0
FB output Data 3
– – – – –
–
–
Q
1
1) Status 1 if a new value is present that is transferred from the
NET network.
Mode
Data 1
NET-ID
1
0
NET-ID 1
..
..
7
NET-ID 8
Parameters
Data 3
Instance
2
0
PT01
..
..
31
PT32
1) Number of station sending the value. Possible station numbers:
01 to 08
2) Send FB (e.g. PT 20) of the sending NET station. Possible
station numbers: 01 – 32
