Read/write image data
For more information visit: www.EatonElectrical.com
MN05013001E
119
Example 2
Write marker word MW32 with 823
823
dec
= 337
hex
J
Data 1 = 37
hex
, Data 2 = 03
hex
Byte
Meaning
Value (hex), sent by
Master
Slave
0
Toggle byte
81
80
1
Command: Write
B1
–
Response:
Write successful
–
C1
2
Len
02
02
3
Type
0D
0D
4 Index
20
20
5
Data 1
37
00
6
Data 2
03
00
7
Data 3
00
00
8
Data 4
00
00
