NAC Controller PEP 2S4082-25 Module Specifications
Enterasys NAC Controller Hardware Installation Guide A-5
NAC Controller PEP 2S4082-25 Module Specifications
Table A‐7 provides the I/O ports, processors and memory, physical, and environmental module
specifications for the 2S4082‐25.
Table A-7 Specifications for 2S4082-25
Item Specification
Ports
Ports 1 through 24 Twenty-four 10BASE-T/100BASE-TX/1000BASE-T compliant
ports through twenty-four RJ45 connectors.
Network Expansion Module slot The NAC Controller Engine is pre-installed.
Processors/Memory
Processor MPC750CX, 400 MHz processor
Dynamic Random Access Memory
(DRAM) 256 MB
FLASH Memory 32 MB
Physical
Dimensions 46.43 H x 6.05 W x 29.51 D (cm)
18.28 H x 2.38 W x 11.62 D (in.)
Approximate Weight Gross: 5.54 kg (12.0 lb.) (shipping carton containing one
module)
Net: 4.10 kg (9.0 lb) (one module without packaging)
Calculated hours for Mean Time
Between Failures (MTBF) for the
2S4082-25 Refer to the MTBF web site at URL
http://www.enterasys.com/support/mtbf/
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -30°C to 73°C (-22°F to 164°F)
Operating Relative Humidity 5% to 90% (non-condensing)
