Enterasys NAC Controller Hardware Installation Guide 3-1
3
Enterasys Matrix N1 Chassis Setup
This chapter contains instructions on setting up the Enterasys Matrix N1 Chassis.
Equipment needed:
• Phillips screwdriver
• Flat blade screwdriver
A Phillips screwdriver is needed to install the unit in a 48.26‐centimeter (19‐inch) equipment rack
Refer to
Chapter 2 for the guidelines that must be followed to install the Enterasys Matrix N1
Chassis.
Follow the order of the sections below for correct installation.
Unpacking the Enterasys Matrix N1 Chassis
Before unpacking the chassis, examine the outside packaging for obvious damage. To unpack the
Enterasys Matrix N1 Chassis proceed as follows:
1. Open the box and remove the packing material protecting the Enterasys Matrix N1 chassis.
2. Remove the power cords, documentation, Electrostatic Discharge (ESD) wrist strap, and
adhesive feet (for standalone placement).
3. Verify the contents of the carton as listed in the table below.
Electrical Hazard: Only qualified personnel should install or service this unit.
Riesgo Eléctrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida.
Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch
ausgebildetes und qualifiziertes Personal vorgenommen werden.
For information about... Refer to page...
Unpacking the Enterasys Matrix N1 Chassis 3-1
Setting Up the Enterasys Matrix N1 Chassis 3-2
Installing the Chassis on a Flat Surface 3-2
Installing the Chassis into a Rack 3-3
Powering Up a Enterasys Matrix N1 Chassis 3-5
Cooling Fans 3-6
Note: Unpack the Matrix 2S4082-25-SYS and 7S4280-19-SYS chassis components only as
needed. Leave the components in their respective shipping cartons until you are ready to install
that component. Save all shipping materials in the event that the chassis has to be repacked.
