7C111 Chassis Specifications and Regulatory Compliance
Enterasys NAC Controller Hardware Installation Guide A-3
NAC Controller Engine Interface Specifications
Table A‐5 provides the Input/Output ports, processor and memory, physical, and environmental
specifications for the NAC Controller Engine (same on both ‐SYS models).
Table A-5 NAC Controller Engine Specifications
Item Specification
Ports
External Gigabit Ethernet Ports (2) When referring to these ports with NAC Controller PEP CLI
commands, use the following syntax to designate port type,
slot location, and port number:
ge.1.port#
where ge is the port type, 1 specifies the the slot location of
the single-slot NAC Controller PEP within the chassis, and
port# is the port number. The port # will be designated as
the next sequential ge port after the last ge port on the NAC
Controller PEP.
Mini-GBIC slots can be mix-and-match, 1000BASE-SX, -LX,
-ELX and 1000BASE-T compliant Minii-GBICs. Refer to
“
Mini-GBIC Input/Output Specifications ” on page A-7.
Internal Gigabit Ethernet Ports (2) The two internal ports connect to the on-board processor
and are used by the installed NAC Controller Engine
software. These ports have the same capabilities as any
other NAC Controller PEP port.
When referring to these ports with NAC Controller PEP CLI
commands, use the following syntax to designate port type,
slot location, and port number:
pc.1.port#
where pc is the port type, 1 specifies the the slot location of
the single-slot NAC Controller PEP within the chassis, and
port# is the port number, either 1 or 2.
RS 232 Serial COM Port Provides connection for Local Management. This port may
be used for NAC Controller initialization.
VGA Port Provides display monitor connection.
10/100 Ethernet Port Can be used for NAC Controller initialization, management,
or network connection.
USB Port Provides USB connection.
Processor/Memory
Processor Pentium M 14 GHz Processor
Dynamic Random Access Memory
(DRAM) 1 GB
Hard Drive 60 GB 2.5 inch drive
External Power Supply
AC Input Voltage 100—200V
AC Input Amps 1.5A
Frequency 50-60Hz
