DJI Mavic 3 Pro Drone with Fly More Combo & RC - Manual (Page 103)

DJI Mavic 3 Pro User Manual
© 2023 DJI All Rights Reserved.
103
DJI 100W USB-C Power Adapter:
Max 100 W (total)
When both ports are used, the max output power of one port is 82
W, and the charger will dynamically allocate the output power of
the two ports according to the power load.
Rated Power DJI 65W Portable Charger: 65 W
DJI 100W USB-C Power Adapter: 100 W
DJI RC Pro
Operating Temperature
-10° to 40° C (14° to 104° F)
GNSS GPS + Galileo + GLONASS
Battery Li-ion (5000 mAh @ 7.2 V)
Battery Type Li-ion
Chemical System LiNiMnCoO2
Operating Time Approx. 3 hours
Storage Capacity Internal Storage (ROM): 64 GB
Support microSD card to expand capacity
Video Transmission
Video Transmission
System O3+
Operating Frequency [3] 2.400-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)
Wi-Fi
Protocol
802.11 a/b/g/n/ac/ax
Support 2×2 MIMO Wi-Fi
Operating Frequency [3] 2.400-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth
Protocol Bluetooth 5.1
Operating Frequency 2.400-2.4835 GHz
Transmitter Power (EIRP) <10 dBm
DJI RC
Operating Temperature
-10° to 40° C (14° to 104° F)
GNSS GPS + Galileo + BeiDou
Battery 5200 mAh
Battery Type Li-ion
Chemical System LiNiMnCoO2
