Page 79

79
14. When you finish selecting settings, select
Return
and press
Enter
to return to the
Network
Settings
menu.
15. Select
Set
, and follow the on-screen instructions to save your settings and exit the menus.
Note:
If a critical problem causes a projector to shut down, you may not receive an e-mail alert.
Network Projector E-mail Alert Messages
Parent topic:
Using the Projector on a Network
Related references
Input Signal Settings - Signal I/O Menu
Network Projector E-mail Alert Messages
When a problem occurs with a networked projector, and you selected to receive e-mail alerts, you
receive an e-mail containing the following information:
• The email address entered as the
From
setting
•
Epson Projector
on the subject line
• The name of the projector experiencing a problem
• The IP address of the affected projector
• Detailed information about the problem
Note:
If a critical problem causes a projector to shut down, you may not receive an e-mail alert.
Parent topic:
Setting Up Projector Network E-Mail Alerts
Setting Up Monitoring Using SNMP
Network administrators can install SNMP (Simple Network Management Protocol) software on network
computers so they can monitor projectors. If your network uses this software, you can set up the
projector for SNMP monitoring.
1.
Press the
Menu
button.
2.
Select
Network
>
Network Settings
>
Projector Control
>
SNMP
>
On
.
