83
Appendix
7
System Parameter Area
6
Version
Address
Parameter Name
Sys.Ex.Value
Meaning of Value
02H 00H 00H
System Version Major
00H–09H
Version Number (Read Only)
02H 00H 01H
System Version Minor (1)
00H–09H
Version Number (Read Only)
02H 00H 02H
System Version Minor (2)
00H–09H
Version Number (Read Only)
6
System
Address
Parameter Name
Sys.Ex.Value
Meaning of Value
02H 01H 00H
HDCP
00H–01H
OFF, ON
02H 01H 01H
FRAME RATE
00H–01H
59.94, 50Hz
02H 01H 02H
SYSTEM FORMAT
00H–02H
720p, 1080i, 1080p
02H 01H 03H
CUT SW ASSIGN
00H–04H
H
AUTO TAKE,
H
AUTO TAKE
I
,
H
CUT,
H
CUT
I
,
H
TRANSFORM
02H 01H 04H
AUTO SW ASSIGN
00H–04H
AUTO TAKE
I
,
H
AUTO TAKE
I
, CUT
I
,
H
CUT
I
, TRANSFORM
I
02H 01H 05H
PANEL OPERATION
00H–01H
A/B, PGM/PST
02H 01H 06H
AUX LINKED PGM
00H–02H
OFF, AUTO, MANUAL
02H 01H 07H
OUTPUT FADE LEFT ASSIGN
00H–0CH
BLACK, WHITE, AUDIO, BLACK&AUDIO, WHITE&AUDIO, STILL 1–8
OUTPUT
02H 01H 08H
OUTPUT FADE RIGHT ASSIGN
00H–0CH
BLACK, WHITE, AUDIO, BLACK&AUDIO, WHITE&AUDIO, STILL 1–8
OUTPUT
02H 01H 09H
USER 1 SW ASSIGN
00H–23H
N/A, FREEZE, AUTO SWITCHING, BPM TAP, INPUT 1–8 ASSIGN,
STILL 1–8 OUTPUT, INPUT 1–8 MUTE, AUDIO IN MUTE,
OUTPUT MUTE, AUX MUTE, INPUT SCAN N, INPUT SCAN R,
MEMORY SCAN N, MEMORY SCAN R, REC START/STOP
02H 01H 0AH
USER 2 SW ASSIGN
00H–23H
N/A, FREEZE, AUTO SWITCHING, BPM TAP, INPUT 1–8 ASSIGN,
STILL 1–8 OUTPUT, INPUT 1–8 MUTE, AUDIO IN MUTE,
OUTPUT MUTE, AUX MUTE, INPUT SCAN N, INPUT SCAN R,
MEMORY SCAN N, MEMORY SCAN R, REC START/STOP
02H 01H 0BH
LED DIMMER
01H–08H
1–8
02H 01H 0CH
LCD DIMMER
01H–08H
1–8
02H 01H 0DH
ON SCREEN MENU
00H–03H
UPPER LEFT, UPPER RIGHT, LOWER LEFT, LOWER RIGHT
02H 01H 0EH
TALLY FRAME
00H–01H
OFF, ON
02H 01H 0FH
AUX/PinP MARK
00H–01H
OFF, ON
02H 01H 10H
AUDIO LEVEL METER SW
00H–01H
OFF, ON
02H 01H 11H
AUDIO LEVEL METER AUDIO IN
00H–02H
OFF, LOWER, UPPER
02H 01H 12H
MULTI-VIEW LABEL
00H–01H
OFF, ON
02H 01H 13H
MULTI-VIEW LAYOUT
00H–03H
PVW.PGM, PGM.PVW, BLACK.PGM, PGM.BLACK
02H 01H 14H
OUTPUT 3 OSD ON SCREEN MENU
00H–01H
OFF, ON
02H 01H 15H
OUTPUT 3 OSD TALLY FRAME
00H–01H
OFF, ON
02H 01H 16H
OUTPUT 3 OSD LABEL/LEVEL METER/MARK
00H–01H
OFF, ON
02H 01H 17H
AUTO INPUT DETECT
00H–01H
OFF, ON
02H 01H 18H
AUTO OFF
00H–01H
OFF, ON
02H 01H 19H
TEST PATTERN
00H–05H
OFF, 75% COLOR BAR, 100% COLOR BAR, RAMP, STEP, HATCH
02H 01H 1AH
TEST TONE
00H–03H
OFF, -20dB@1kHz, -10dB@1kHz, 0dB@1kHz
6
Panel Lock
Address
Parameter Name
Sys.Ex.Value
Meaning of Value
02H 02H 00H
A/PGM 1 SW
00H–01H
OFF, ON
02H 02H 01H
A/PGM 2 SW
00H–01H
OFF, ON
02H 02H 02H
A/PGM 3 SW
00H–01H
OFF, ON
02H 02H 03H
A/PGM 4 SW
00H–01H
OFF, ON
02H 02H 04H
A/PGM 5 SW
00H–01H
OFF, ON
02H 02H 05H
A/PGM 6 SW
00H–01H
OFF, ON
02H 02H 06H
A/PGM 7 SW
00H–01H
OFF, ON
02H 02H 07H
A/PGM 8 SW
00H–01H
OFF, ON
02H 02H 08H
B/PST 1 SW
00H–01H
OFF, ON
02H 02H 09H
B/PST 2 SW
00H–01H
OFF, ON
02H 02H 0AH
B/PST 3 SW
00H–01H
OFF, ON
02H 02H 0BH
B/PST 4 SW
00H–01H
OFF, ON
02H 02H 0CH
B/PST 5 SW
00H–01H
OFF, ON
02H 02H 0DH
B/PST 6 SW
00H–01H
OFF, ON
02H 02H 0EH
B/PST 7 SW
00H–01H
OFF, ON
02H 02H 0FH
B/PST 8 SW
00H–01H
OFF, ON
