Menu List
List of Shortcut Keys
You can set the following items without entering a menu.
Menu item
Operation
Remarks
MIX/WIPE
MIX TYPE
Hold down the [TRANSITION] button and turn the SPLIT/VFX [A] knob
TRANSITION TYPE: MIX
WIPE TYPE
Hold down the [TRANSITION] button and turn the SPLIT/VFX [A] knob
TRANSITION TYPE: WIPE
WIPE DIRECTION
Hold down the [TRANSITION] button and turn the SPLIT/VFX [B] knob
WIPE BORDER COLOR
Hold down the [TRANSITION] button and turn the SPLIT/VFX [A] knob while
pressing
WIPE BORDER WIDTH
Hold down the [TRANSITION] button and turn the SPLIT/VFX [B] knob while
pressing
SPLIT/VFX A
SPLIT/VFX TYPE
Hold down the SPLIT/VFX [A] button and turn the SPLIT/VFX [A] knob
AREA SIZE
Hold down a Cross-point A [1]–[8] button and turn the SPLIT/VFX [A] knob
VFX/SPLIT TYPE :
PART MOSAIC, BACKGROUND MOSAIC
BLOCK SIZE
Hold down a Cross-point A [1]–[8] button and turn the SPLIT/VFX [A] knob
while pressing
CENTER POSITION
Turn while pressing the SPLIT/VFX [A] knob
VFX/SPLIT TYPE : SPLIT V, SPLIT H
SPLIT/VFX B
SPLIT/VFX TYPE
Hold down the SPLIT/VFX [B] button and turn the SPLIT/VFX [A] knob
AREA SIZE
Hold down a Cross-point B [1]–[8] button and turn the SPLIT/VFX [B] knob
VFX/SPLIT TYPE :
PART MOSAIC, BACKGROUND MOSAIC
BLOCK SIZE
Hold down a Cross-point B [1]–[8] button and turn the SPLIT/VFX [B] knob while
pressing
CENTER POSITION
Turn while pressing the SPLIT/VFX [B] knob
VFX/SPLIT TYPE : SPLIT V, SPLIT H
INPUT 1–8
INPUT ASSIGN
Hold down the [EXIT] button and press a Cross-point A or B [1]–[8] button
Switches the still image (STILL 1–8)
assigned to each input channel
