Roland Aerophone Pro Digital Wind Instrument - Manual (Page 14)

14
Making Settings in the Menu
Indication Value Explanation
Output Volume 0–11 Specifies the volume that is output from the OUTPUT jack or from headphones connected to the PHONES jack.
Output Mode Stereo, Mono Sets whether the audio signal output from the PHONES or OUTPUT jack is outputted in stereo or in mono.
Breath Curve
Specifies how the sound responds to the force of your breath (breath sensitivity).
L5–L1
We recommend these settings if you’re a beginning wind instrument
player.
Fortissimo (ff) can be produced even by blowing relatively softly.
Breath force
Lev
el
M
H1
H5
L1
L5
M This is the usual setting.
H1–H5
We recommend these settings for experienced wind instrument players.
Fortissimo (ff) is produced only when you blow quite strongly.
Bite Ctrl Mode
These parameters set how the bite sensor controls the sound.
Off Turns off the bite sensor control.
Sax
Reducing the strength of your bite on the reed makes the pitch fall.
Weakening the strength of your bite on
the reed lowers the pitch
E-Wind
Cyclically varying the strength of your bite on the reed applies vibrato.
Apply vibrato by repeatedly strengthening and
weakening the strength of your bite on the reed
Bend Range Source System, Scene
Selects whether the bend range in system settings (System) or the bend range set in each scene (Scene) is
used when operating the pitch bend.
Bend Range Mode
These parameters switch between bend range modes.
Normal
Either the Bend Range Bite, Bend Range Motion or Bend Range Ctrl (whichever is larger) is used for the bend
range.
When you use both bite control and the thumb lever or other bend controls together, the bend range is
limited to the maximum or minimum value and does not operate beyond
this.
Advance
Automatically calculates the bend range using the combination of Bend Range Bite, Bend Range Motion and
Bend Range Ctrl.
Asgn Src Breath
System, Scene
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameter that is assigned to the breath control.
Asgn Src Bite
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameter that is assigned to the bite control.
Asgn Src Lever
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameter that is assigned to the thumb lever.
Asgn Src Thumb Pad
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameter that is assigned to the thumb pad.
Asgn Src Motion
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameter that is assigned to the motion control.
Asgn Src S1/S2
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameters assigned to the [S1]/[S2] buttons.
Asgn Src Key
Selects whether to use the system settings (System) or the settings in each scene (Scene) for the Assign or MIDI
parameters assigned to the performance keys.
Harmony Source Selects whether to use the system harmony settings (System) or the harmony settings in each scene (Scene).
Scene Shortcut Off, On
This turns the shortcut function on/off, which is useful for switching between scenes.
& “Shortcut” (p. 22)
Bluetooth Off, On Turns the Bluetooth function on/off.
Bluetooth ID Off, 1–9
If you are pairing with your smartphone in a location where there are multiple Aerophone Pro units, you can
assign an ID to each unit. When you specify a Device ID, the specified number is added to the end of the device
name that is shown on your smartphone or app.
Example) “AE-30 AUDIO 1” “AE-30 1” etc.
* To enable the ID that you set, turn this instrument’s power off and then on.
BT Audio Pairing (Pairing Start)
Perform the pairing to use Bluetooth audio.
& “Playing back songs from your smartphone” (p. 11)
MIDI Ctrl PC Off, On When the MIDI control mode is on, this switches the program change message output on/off.
MIDI Ctrl BS Off, On When the MIDI control mode is on, this switches the bank select (MSB, LSB) output on/off.
Key Delay 0–10
Sets the time it takes for the performance keys to actually produce sound when you play them.
Unintended notes can be sounded due to inconsistent fingering when you press or release multiple keys
simultaneously.
The larger the value, the less likely it is for unintended notes to sound.
