23
Detailed Function Settings (Menu)
1.
Press the [MENU] button.
The MENU screen appears.
2.
Touch the desired menu item in the screen.
3.
Edit the settings of the selected menu.
MEMO
For details on the contents of each menu item, refer to “Reference
Manual” (PDF).
Menu Explanation
TONE EDIT Edit a tone (p. 14).
EFFECTS EDIT Edit the effects (p. 14).
ZONE EDIT Edit a zone (p. 14).
SCENE EDIT Make settings for an entire scene (p. 12).
MIXER Adjust the pan and the volume balance.
SYSTEM Make overall settings for the entire this unit.
UTILITY Back up data or initialize this unit (p. 23).
Backing up User Data (Backup/Restore)
Here’s how all settings stored in this unit’s internal memory can be saved to an USB
flash drive (backed up), or written back into internal memory (restored).
Saving Data to USB Flash Drive (BACKUP)
NOTE
If you back up using the same file name as backup data that already exists
on the USB flash drive, the existing data will be overwritten. Assign a
different name if you want to make a new backup.
1.
Press the [MENU] button.
The MENU screen appears.
2.
Touch .
The UTILITY screen appears.
3.
Touch .
4.
If you want to rename the backup file, touch and
assign a name (p. 10).
After editing the name, touch to close the window.
5.
Touch .
A confirmation message appears.
To cancel, touch .
6.
To execute, touch .
NOTE
Never turn off the power or remove the USB flash drives while the
screen indicates “working.”
Restoring Saved Data from USB Flash Drive (RESTORE)
NOTE
When you execute the restore operation, all settings currently saved in this
unit will be lost. If you want to keep the current settings, back them up
using a different name.
1.
In the UTILITY screen, touch .
2.
Touch the file that you want to restore, and then touch
.
A confirmation message appears.
To cancel, touch .
3.
To execute, touch .
NOTE
Never turn off the power or remove the USB flash drives while the
screen indicates “working.”
4.
Turn the power off, and then on again (p. 8).
Returning to the Factory Settings (Factory Reset)
Here’s how you can restore this unit’s settings to their factory-set condition
(factory reset).
NOTE
When you execute the Factory Reset operation, all data in this unit will be
lost. If there is any data that you want to keep, back it up to an USB flash
drive.
1.
In the MENU screen, touch .
2.
Touch .
A confirmation message appears.
To cancel, touch .
3.
To execute, touch .
NOTE
Never turn off the power while the factory reset is in progress.
Main Specifications
Settings
Roland FANTOM : Music Workstation
FANTOM-6 FANTOM-7 FANTOM-8
Keyboard
61 Keys semi-weighted key-
board and channel aftertouch
76 Keys semi-weighted key-
board and channel aftertouch
88 Keys PHA-50 Wood and
Plastic Hybrid Structure and
channel aftertouch
Power
Supply
AC 117-240 V
Current
Draw
50W
Dimensions
1,084 (W) x 403 (D) x 106 (H) mm
42-11/16 (W) x 15-7/8 (D) x 4-3/16 (H) inches 1,296 (W) x 403 (D) x 106 (H) mm
51-1/16 (W) x 15-7/8 (D) x 4-3/16 (H) inches 1,432 (W) x 439 (D) x 153 (H) mm
56-7/16 (W) x 17-5/16 (D) x 6-1/16 (H) inches
Weight
15.3 kg
33 lbs 12 oz 17.7 kg
39 lbs 1 oz 27.7 kg
61 lbs 2 oz
Accessories
Owner’s Manual
Power Cord
Options
Keyboard stand: KS-10Z, KS-12 Keyboard stand: KS-10Z, KS-12
Keyboard stand: KS-G8B, KS-
10Z, KS-12
Pedal Switch: DP series, RPU-3
Expression Pedal: EV-5
USB flash drive (*1)
*1 Use a commercially available USB flash drive. However, we cannot guarantee that all commercially available USB
flash drives will work.
* This document explains the specifications of the product at the time
that the document was issued. For the latest information, refer to the
Roland website.
MEMO
For details on how to place this unit on a stand, refer to “Reference
Manual” (PDF).
