Page 11
Product Description
5
Figure 3
Component location, rear of XDF
Condenser air intakes,
perforated grilles
Service access for
gauges to be inserted
for testing
Three-phase electrical
cord, 10 feet (3m)
Single-phase electrical cord,
10 feet (3m)
Condensate drain
Backup ventilation
damper (air exit)
Rear door
Condenser fan
(removable to reduce
height temporarily)
Casters
Stabilizing foot
(one of four)
Door handle
SELF-CONTAINED
AIR COOLED MODEL
Service access for
gauges to be inserted
for testing
Three-phase electrical
cord, 10 feet (3m)
Single-phase electrical cord,
10 feet (3m)
Condensate drain
Backup ventilation
damper (air exit)
Rear door
Return Line
(1" female,
NPT)
Casters
Stabilizing foot
(one of four)
Door handle
Supply Line
(1" female, NPT)
WATER/GLYCOL COOLED MODEL
