Jumper States

There are three sets of jumper settings located on the back of the module.



MODE 3 - Development Mode Jumper: (Top Jumper) Used for firmware

updates only. The two pins should NOT be jumpered during normal
operation.



MODE 2

– Default IP Jumper: (Middle Jumper) The default IP address

of the ProSoft gateway is 192.168.0.250. Set this jumper to put the
gateway's IP address back to the default. The two pins should NOT be
jumpered during normal operation.



MODE 1

– (Bottom Jumper) Reserved
