PLX8x-MNET-61850 ♦ Communication Gateway Diagnostics and Troubleshooting
Modbus TCP/IP to IEC 61850 User Manual
ProSoft Technology, Inc. Page 109 of 228
May 14, 2014
Driver Status
Status Description
Remote Node Status This displays a bitmap of 1s or 0s, to indicate the
communication status of each IED where 1=communication is
good, and 0=no communication.
Command Read Requests The count of total IEC61850 (MMS type) read command
requests sent to nodes defined in the configuration file
Command Write Requests The count of total IEC61850 (MMS type) write command
requests sent to nodes defined in the configuration file
Command Read Errors The count of total IEC61850 (MMS type) read errors received
from requests sent to nodes defined in the configuration file
Command Write Errors The count of total IEC61850 (MMS type) write errors received
from requests sent to nodes defined in the configuration file
GOOSE messages Processed The total count of GOOSE messages received per all
subscriptions defined in the current operating configuration of
the IEC61850 driver
Report Messages Processed The total count of reports received per all reports that are
enabled, and present in the current operating configuration of
the IEC61850 driver
Identification Response Errors The total count of Identification response errors per the
nodes/devices defined in the current operating configuration
of the IEC61850 driver
Create DataType Errors The total count of errors received when making a request for
datatypes defined for the configured commands in the current
operating configuration of the IEC61850 driver
Remote Node Config
Command Description
Remote Node Configured
Index, or (Not Configured)
Value is the current index used of the addressed node, indicating
that the node is configured in the current operating configuration
file… or the value will indicate that the node is not configured
Remote Node IP Address The IP Address of the indexed node being requested that is
defined in the configuration file
Remote Node Name The Node Name identifier of the indexed node being requested
that is defined in the configuration file
Command Index Entry(s) Lists the commands defined in the configuration file for the indexed
node being requested, where each command entry is defined with
this start tag to identify the command with a unique entry index
used
Command Domain Name Identifies the Domain Name used when accessing the IEC61850
variable via the command entry index in the previously returned
information
Command Datapath Name Identifies the Datapath Name used when accessing the IEC61850
Data Attribute via the command entry index in the previously
returned information
Command Tag name(s) Identifies the g ateway’s tag names for the command, which are
allocated in the current operating configuration file for the indexed
command entry
