- 1 -
1. SPECIFICATIONS
Model EX21D
Type
Air-Cooled, 4-Cycle, Slant Single-Cylinder,
Horizontal P .T .O . Shaft, OHC Gasoline Engine
Bore & Stroke mm (in.) 67 x 60 (2 .64 x 2 .36)
Piston Displacement ml (cu.in.) 211 (12 .87)
Compression Ratio 8 .5
Continuous Output kW(HP)/r.p.m.
3 .2(4 .4)/3000
3 .7(5 .0)/3600
Maximum Output kW(HP)/r.p.m. 5 .1(7 .0)/4000
Maximum Torque N • m / r.p.m.
(kgf • m / r.p.m.)
(ft • lb. / r.p.m.)
13 .9/2500
(1 .41/2500)
(10 .26/2500)
Direction of Rotation Counterclockwise as viewed from the P .T .O . shaft side
Valve Arrangement Overhead cam system
Cooling System Forced air cooling system
Lubrication System Splash lubrication system
Lubricant
Automobile engine oil ; Grade SE or higher (SG,SH or SJ in recomended)
SAE 10W-30-----Under ordinary atmospheric temperatures
SAE 5W-30-------In cold areas
Capacity of Lubricant L 0 .6
Throttle body Electronic Fuel injection
Fuel Automobile unleaded gasoline
Fuel Consumption Rate g/kW • h (g/HP • h) 367 (270) at continuous rated output
Fuel Supply System Diaphragm pump (Pulse type)
Fuel Tank Capacity L 3 .6
Ignition System Transistorized magneto
Spark Plug NGK BR-6HS
Starting System Recoil starter
Governor System Centrifugal flyweight system
Dry Weight kg (lb.) 16 (35 .28)
Dimensions (L x W x H) mm (in.) 321 x 369 x 335 (12 .6 x 14 .5 x 13 .2)
