- 50 -

7-4-3

BASIC THEORY

(a) Revolution of the flywheel generates electricity on the primary side of the ignition coil (

), and the base

current I

1

flows to the power transistor (

). Current I

1

turns the power transistor “ON” and the electric

current I

2

flows. This is the same situation when the contact breaker is closed in a case of breaker point

type ignition system.

(b) At lower engine revolution, the low speed ignition timing control circuit (

) operates to run the gate

current I

3

to

turn the control thyristor (

) “ON”, thus the current I

1

bypass the thyristor as current I

5

.

At this moment, the power transistor (

) turns “OFF” and the current I

2

is shut off abruptly resulting

in the high voltage generated in the secondary coil (

) which produces sparks at the spark plug.

The ignition timing at lower engine revolution is less advanced as shown in the above chart.

(c) At higher engine revolution (over 2,000rpm), advancing control circuit (

) operates to run the gate current

I

4

to turn the control thyristor (

) “ON”, thus the current I

1

bypass the thyristor as current I

5

.

At this moment, the power transistor (

) turns “OFF” and the current I

2

is shut off abruptly resulting

in the high voltage generated in the secondary coil (

) which produces sparks at the spark plug.

At over 2,000rpm, ignition timing on each engine revolution is controlled by advancing control circuit (

)

that receive electrical information from revolution sensing resister (

).

The advancing of ignition timing from lower to higher engine revolution changes lineally as shown in

the above chart.

Fig.7-2b

7-4 IGNITION SYSTEM (EX27)

7-4-1

IGNITION COIL INTERNAL CIRCUIT

7-4-2

IGNITION TIMING CHARACTERISTIC

Fig.7-2a

3

4

0

0

500

1000

1500

2000

2500

3000

3500

4000

5

10

15

20

25

30

35

5

2

6

1

7

I

3

I

4

I

1

I

2

Low Speed Ignition
Timing Control
Circuit

Base Resister

Advancing Control
Circuit

Contr

ol th

yristor

I

5

Re

v

olution Sensing

Resister

P

o

wer T

ransistor

Primar

y Coil

Spark Plug

Secondar

y Coil

IGNITION TIMING

B.T.D.C.

( )

LINEAR ADVANCING

ENGINE REVOLUTION (R.P.M.)
